FIA Standard CAD Template PRO [UK Metric]

  • £24.99
  • Save £15


This AutoCAD template provides you with a great starting point for your drawings. It includes everything in the Basic Template plus lots of extras that will make your drawings look better and your workflow easier.

This template is in METRIC units! AutoCAD 2010 or later.

How many times have you opened a new drawing and spent too much time searching for the correct layers to use, copying stuff from other drawings and generally getting set up before you have a chance to actually draw anything!

Then, when it comes to printing, you spend ages setting up plot sheets, plot styles and line weights before you get anything on paper. Very frustrating and time consuming.

This template will put a stop to the time wasting and allow you to get straight into your design without the fuss.

Everything from the Basic Template:


  • Two sets of CAD layering according to your needs
  • Line weights set up ready to use
  • Text and dimension styles ready to use
  • Elevation and Section markers
  • Level markers
  • North points
  • Dynamic scale bar
  • Hatch patterns
  • Line weight and style options
  • Electrical Symbols
  • Sun path diagrams (London)
  • People blocks in elevation
  • People blocks in plan
  • Tree blocks in plan and elevation
  • Door blocks
  • Window blocks
  • Furniture blocks
  • Stair blocks in plan
  • Sanitary and kitchen fittings
  • Layout sheets set up in A0, A1, A2, A3 and A4
  • Example plan and elevation

Plus:

  • Kitchen Furniture CAD blocks
  • Bedroom Furniture CAD blocks
  • Living Room Furniture CAD blocks
  • Kitchen CAD blocks
  • Dining Furniture CAD blocks
  • Bathroom CAD blocks
  • General Standard Furniture Sizes CAD blocks
  • Standard Door Sizes CAD blocks
  • Window CAD blocks in section, elevation and plan
  • Accessible sanitary facilities CAD blocks
  • Average sizes of people standing
  • Average sizes of people sitting
  • Average wheelchair user dimensions
  • Site analysis symbols
  • Steel beam CAD blocks
  • More hatches for easy 'match properties'
  • Dynamic Section Markers for easy stretching
  • Dynamic Windows and Doors for easy re-sizing
  • Dynamic Furniture blocks for quick selection
  • Dynamic trees for easy scaling
  • 2 Additional title block styles for layout sheets

The template zip file that will be ready to download instantly includes:

**Cad template (.dwg and .dwt) AutoCAD 2010 or later

**Colour table file (.ctb) for printing

**Guidance document

The template contains many of our premium furniture cad block sets. This template is the perfect addition to your cad library, helping you save time, and allowing you to adjust it to your requirements.
