About Understanding Architectural Details - Residential
[Published June 2022]
Understanding Architectural Details – Residential, is dedicated to residential construction. The book is packed full of over 120 construction details in 2D, and 120 construction details in 3D.
We look at the principles behind construction detailing, and delve deep into each area of the building to make sure you have a full understanding of construction design.
Foundations
- strip foundations
- pad foundations
- pile foundations
- raft foundations
Steel Frame Construction
- floors
- walls
- roofs
Masonry Construction
- ground bearing floors
- suspended floors
- walls (including cladding options)
- roofs (flat and pitched)
- doors and windows
Structural Insulated Panels (SIPS)
- floors
- walls
- windows and doors
- roofs
Timber Frame Construction
- ground bearing floors
- suspended floors
- walls (including cladding options)
- roofs (flat and pitched)
- doors and windows
Insulated Concrete Formwork (ICF)
- floors
- walls
- windows and doors
- roofs
PLUS:
- functional requirements
- detailing principles
- materials
- notes on the building regulations
- even more details than before!
Green Roof Construction
- intensive
- extensive
How this book will help you
Gain a better understanding of residential construction
Understand the principles of construction detailing
Understand the functional requirements of a building in relation to the building regulations
Learn about the different materials available and their benefits
Improve your technical ability
Increase your skill set to make you more employable
Save a huge amount of time searching for details, over 120 details in one place
Who is it for?
students | graduates | professionals | tutors | professors
This book is really useful to quite a few different people:
Students looking to increase their knowledge of construction.
Graduates use the book to take out into the workplace and use as a reference.
Professionals use the book as a reference book and foundation for their construction libraries.
The book is also highly recommended by many tutors, lecturers and professors who teach construction at colleges and universities around the globe.
What do I get?
Understanding Architectural Details Residential Bundle 1 includes:
PDF file of the book
How do I get it?
After purchase you will receive an email confirming your order - so please make sure you enter your email address correctly.
You will then receive a second email with the download link to get your book. Please check your junk or spam folders!
If you haven't received your link after about 10 minutes - please contact us.
Testimonials
Understanding Architectural Details, Emma Walshaw’s series of books and downloads are a valuable resource for students and professionals alike. She has really filled a hole in the market, particularly with the CAD and 3D downloads which offer standard construction build-ups that can be clearly understood.
Michael - Architecture Student
I don’t think I have ever seen such a comprehensive resource and clear cut explanation for architectural details!
I wish you the best of luck and look forward to seeing your future work, the 3d models are top notch and critical in spatially understanding the construction methods.
Alex- Architectural Technologist
I have to say it is a really great resource and reference guide, and is very well put together. The sections at the front of the book (Functional Requirements) is particularly useful, and has joined the small collection of architectural and construction guides/handbooks that I refer to when I need my memory jogged or details/specifications clarified.
All of the drawings and details are well put together, clear and concise. Again a great reference.
Matt - Architect
I have found the residential book extremely useful , I was recommended it by a tutor for a module I was doing and this was just before I started work in practice so it gave me a head start for my new job getting to see all similar details from your book in real life situations. Thank you!
George - 3rd Year Student
Other Books in This Range
Bundle 2 includes all the CAD files from the book. Bundle 3 includes all the CAD files and SketchUp files from the book.
Need some clarification?
Check out our Books - Further Information page by clicking the button below. This clarifies the books available, who they are for, what you get and any other questions you might have.
Looking for a hard copy?
You can get the paperback version of this book on Amazon.com.
FAQ
*Please Note: if you are a university, institution or library, the digital books are not permitted for purchase. Please purchase hard copies by clicking on the 'Hardcopy Books' link or check out the other options available here.
Alternatively please contact us to discuss available options hello@firstinarchitecture.co.uk*
